FS-8700-127 Hanning & Kahl HCS-R Manual
Page 17 of 17
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: 408 262-2299 Fax: 408-262-2269 Toll_Free: 888-509-1970 email: [email protected]
Appendix A.2. How Server expects Data:
The Server expects data in the following format in order to constitute its response to HCS-R Clients.
Appendix A.2.1.
Data_Type is Ana_Input or not specified
Data Array Offset Description
0 - 18
Data bits ( 0 - 1 )
19
Receipt ok ( 0 ), Disturbance ( 1 )
20
From Loop ( 0 ), On Loop ( 1 )
21
Loop Number (0,1,2,3)
Appendix A.2.2.
Data_Type is Digi_Input
Data Array Offset Description
0 - 18
Data bits ( 0 - 1 )
19
Receipt ok ( 0 ), Disturbance ( 1 )
20
From Loop ( 0 ), On Loop ( 1 )
21,22
2 bits for Loop Number
Offsets 21 22
0 0 –Loop 1
1 0 –Loop 2
0 1 –Loop 3
1 1 –Loop 4
