CONFIGURING THE FIELDSERVER AS A HCS-R SERVER
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a Hanning & Kahl HCS-R Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for HCS-R communications, the driver independent FieldServer buffers need to be declared in the
“Data Arrays” section, the FieldServer virtual Node(s) needs to be declared in the “Server Side Nodes” section, and
the data to be provided to the clients needs to be mapped in the “Server Side Map Descriptors” section. Details on
how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
6.1
Server Side Connection Parameters
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device is connected to the
FieldServer
P1-P8
3
Protocol
Specify protocol used
HCS-R
HCSR
H&K HCS-R
Baud*
Specify baud rate
9600 (Vendor Limitation)
Parity*
Specify parity
None (Vendor Limitation)
Data_Bits*
Specify data bits
8 (Vendor Limitation)
Stop_Bits*
Specify stop bits
1 (Vendor Limitation)
Server_Hold_Timeout*
Specifies the time that the FieldServer will reserve the
Server side connection while waiting for the Client side to
update data in Data_Array (if necessary)
>1.0s, 2.0s
Example
// Server Side Connections
Connections
Port , Protocol , Baud , Parity
P8
, HCS-R
, 9600 , None
3
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
