background image

FS-8700-127 Hanning & Kahl HCS-R Manual

Page 15 of 17

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com

Tel: 408 262-2299 Fax: 408-262-2269 Toll_Free: 888-509-1970 email: [email protected]

Appendix A. Reference

Appendix A.1. How Client Stores Data:

The HCS will be polled by an RDBC Map Descriptor and data will be stored in the DA_Current Data Array in the
following fashion if parameter HCSR_Data_Stages >1:

New data is stored as current data.

If data is changed, last current data is moved to 2

nd

Stage, 2

nd

Stage data is moved to 3

rd

stage and 3

rd

stage

data is lost.

When a vehicle has HCS-R equipment installed, Byte 7 (Status of the loop) is equivalent to the “From Loop (0),
On Loop (1) byte listed in Appendix A.1.1. The 20th offset will hold whether data is From Loop or On Loop. To
achieve this, the FieldServer should be configured to store On-Loop and From-Loop data in the same Data
Array. i.e. Map Descriptor Parameter HSCR_Onfrom should be set to Onfrom. Refer to Section 5.3.2

Appendix A.1.1.

Data_Type is Ana_Input or not specified

Data Array Offset

Description

Current Data

0 - 18

Data bits ( 0 - 1 )

19

Receipt ok ( 0 ), Disturbance ( 1 )

20

From Loop ( 0 ), On Loop ( 1 )

21

Loop Number (1,2,3,4) as integer

2

nd

(Previous) Data

24 – 42

Data bits ( 0 – 1 )

43

Receipt ok ( 0 ), Disturbance ( 1 )

44

From Loop ( 0 ), On Loop ( 1 )

45

Loop Number (1,2,3,4) as integer

3

rd

(Prior to previous) Data

48 – 66

Data bits ( 0 – 1 )

67

Receipt ok ( 0 ), Disturbance ( 1 )

68

From Loop ( 0 ), On Loop ( 1 )

69

Loop Number (1,2,3,4) as integer
