FS-8700-127 Hanning & Kahl HCS-R Manual
Page 12 of 17
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: 408 262-2299 Fax: 408-262-2269 Toll_Free: 888-509-1970 email: [email protected]
6.2
Server Side Node Parameters
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for Node
Up
to
32
alphanumeric
characters
Node_ID
Station address of physical server Node
240
Protocol
Specify protocol used
HCS-R
HCSR
H&K HCS-R
Server_Hold_Timeout*
Specifies the time that the FieldServer will reserve the Server
side connection while waiting for the Client side to update data
in Data_Array (if necessary)
>1.0s, 2.0s
Example
// Server Side Nodes
Nodes
Node_Name , Node_ID , Protocol
HCSR_01
, 240
, HCS-R
6.3
Server Side Map Descriptor Parameters
6.3.1 FieldServer Related Map Descriptor Parameters
Column Title
Function
Legal Values
Map_Descriptor_Name Name of this Map Descriptor
Up
to
32
alphanumeric
characters
Data_Array_Name
Name of Data Array where data is to be stored in the
FieldServer
0 to (Data_Array_Length-1) as
specified in Section 4.
Data_Array_Offset
Starting location in Data Array
0 to (Data_Array_Length-1) as
specified in Section 4.
Function
Function of Server Map Descriptor
Passive
Server_Hold_Timeout*
Specifies the time that the FieldServer will reserve the
Server side connection while waiting for the Client
side to update data in Data_Array (if necessary)
>1.0s, 2.0s
