Page 18
Select “Engine Position”
From the “Edit” mode, using the “Up” or “Down” buttons, select the
“Select Engine Position” edit function.
Press and hold the “Up” and “Down” buttons for 2 seconds to select
the “Select Engine Position”. Follow the instructions below.
Otherwise,
Press the “Up” or “Down” button to select another function or
“Mode” to return to “Normal” mode.
Select
Engine
Position
Press the “Up” or “Down” buttons to scroll through the selections.
When the correct choice is next to the selection arrow “>”, Press and
hold the “Up” and “Down” buttons together for 2 seconds to save
the selection.
Select Eng
Position
Port Inner
> Starboard
These selections will appear during scrolling. Only two selections are
displayed at a time. Port
Star Inner
Note: After changing the Engine Position you will need to turn the
MG2000 off then back on for the change to take effect.
The screen returns to the “Edit” mode.
Select
Engine
Position
Press “Up” or “Down” to select another “Edit” mode edit function.
Otherwise,
Press the “Mode” button to return to the “Normal” mode.
Select Display Units - “Pressure Units”
From the “Edit” mode, using the “Up” or “Down” buttons, select the
“Select Display Units” edit function.
Press and hold the “Up” and “Down” buttons for 2 seconds to
select the “Select Display Units”. Follow the instructions below.
Otherwise,
Press the “Up” or “Down” button to select another function or
“Mode” to return to “Normal” mode.
Select
Display
Units
From the “Select Display Units” function, using the “Up” or “Down”
buttons display the “Select Pressure Units” screen.
Press and hold the “Up” and “Down” buttons for 2 seconds to
select “Select Pressure Units.”
Select
Pressure
Units
