AP-2
ZOOM MODE (BOTTOM LOCK, BOTTOM ZOOM,
MARKER ZOOM, DISCRIM-1/2, DISCRIM-1/3)
NO. OF COLORS (8, 16)
HUE (CUSTOM, STD, HUE1-7)
BACKGROUND (BLACK, DARKBLUE, BLUE, LIGHTBLUE, WHITE)
WHITE LINE (OFF, 1-10)
DEPTH INFO (OFF, STD, LARGE, RIGHT)
BOTTOM SEARCH (AUTO, LF, HF)
MARKER SELECT (VRM, WHITE MARKER)
AUTO SHIFT (OFF, ON)
DISPLAY DATA (OFF, L/L, TD, TIMER, GAIN,
R/B, COURSE)
SCROLL TIME (OFF, ON)
SMOOTHING-1 (OFF, 1-8, 3)
SMOOTHING-2 (OFF, ON)
DISP
ALM BOTTOM ALARM (OFF, ON)
(Continued on the next page)
ALARM DEPTH (0-6000ft, 0ft)
ALARM ZONE (1-6000ft, 10ft)
FISH ALARM (OFF, FISH, BTM-FISH)
TEMP ALARM (OFF, WITHIN RANGE, OUT OF RANGE)
ALARM DEPTH (FISH: 0-6000ft, 0ft)
(BTM-FISH: 0.0-600.0ft, 0.0ft)
ALARM ZONE (FISH:1-6000ft, 10ft)
(BTM-FISH:0.1-600.0ft, 1.0ft)
ALARM LEVEL (MIN, MID, MAX)
TEMP LIMIT (20.0-95.0, 65.0 F)
ALARM ZONE (0.1-30.0, 1.0 F)
1
(Continued from previous page)
