3-6
E/S SIG OUT
Outputs selected video sounder signal to external equipment. Default setting is OFF (no output).
In the following cases, the optional EXIF assy. is required for FCV-1200L.
•
When telesounder is connected on sister ship.
•
When recording video sounder signal by picture recorder.
•
When FCV-1200L outputs video sounder signal to other color video sounder.
LF: Outputs the low frequency signal.
HF: Outputs the high frequency signal.
LF/HF: Outputs both the high and low frequency signals.
Note: When selecting LF, HF, or LF/HF, select INTERNAL at XDCR CONNECT.
Equipment connected XDCR CONNECT E/S SIG OUT Remarks
External transceiver unit ETR -
Telesounder on sister ship INTERNAL LF, HF, LF/HF Not available on FCV-
1200LM
Telesounder on master
ship TS/OTHER
-
Record by picture recorder INTERNAL LF, HF, LF/HF Not available on FCV-
1200LM
Play back by picture
recorder TS/OTHER
-
Outputs to other E/S INTERNAL LF, HF, LF/HF Not available on FCV-
1200LM
KP SETTING
Synchronizes transmission with other echo sounders. Select EXTERNAL to synchronize
transmission.
