43
Punch In/Out Recording
Track 5
Track 6
Track 7
Track 8
Auto Punch In point
(Rehearsal In)
Auto Punch Out point
(Rehearsal Out)
Track 1
Track 2
Track 3
Track 4
This part is changed.
Playback
start point
Playback
end point
RHSL
A. PUNCH
Locate Locate
Stop here.
Auto Punch In point Auto Punch Out point
The FD-8 stops at a point that precedes the Auto
Punch In point by the specified preroll time. (0 - 10
seconds)
Auto Punch In point Auto Punch Out point
Auto Return Start point Auto Return End point
Rehearsal area
The FD-8 punches in
automatically at the
Punch In point. The FD-8 punches out
automatically at the
Punch Out point.
Playback starts from the Auto Return Start
point, and you can rehearse Auto Punch In/
Out.
All tracks are in playback
monitoring mode.
Only track 3 in input monitor-
ing. The sound is not recorded
at this time. The RECORD
LED flashes.
All tracks are in playback
monitoring mode.
Rehearsing Auto Punch In/Out recording
In Rehearsal mode, the READY track assumes input monitoring mode between the Auto Punch In and Out points,
and the sound is not recorded. You can practice Auto Punch In/Out operation repeatedly before you proceed to
actual recording. Locate the recording start position slightly before the Auto Punch In point.
Set the preroll value while referring to the “Changing the Initial
Settings (SETUP Mode)” chapter. In this way, the FD-8 can locate
a point that precedes the Auto Punch In point by the specified preroll
value. This enables you to start playback slightly before the Punch
In point. (Refer to page 102 for more information on “Changing the
Initial Settings.”) The FD-8 will repeat playback data between the
AUTO RTN START point and the AUTO RTN END point if you set
the AUTO RTN START point before the Auto Punch In point and
the AUTO RTN END point after the Auto Punch Out point. This
allows you to repeat rehearsal. See the “Hint-2.”.
1. Press the RECORD button while holding down the
SHIFT key.
The [RHSL] indicator flashes in the A.PUNCH mode
indication area of the display. This means that Auto Punch
mode is turned on.
2. Set the track for Auto Punch In/Out to READY.
Press the RECORD RACK select key [3/L] to set track 3 to
READY.
3. Start playback on the FD-8 from a point slightly
before the Auto Punch In point.
Rehearsal starts, and the FD-8 operates as follows:
4. Play the guitar accompanying the playback sound
from tracks 1 - 8 for rehearsal, while adjusting the
recording level.
You will hear the guitar performance between the Auto
Punch In and Out points. Otherwise, you will hear the
recorded guitar sound. Use the channel 1 input fader to
adjust the recording level of the guitar. Turn the channel
MON knobs toward [TRK] to adjust the playback level of
tracks 1-8.
5. When you are satisfied with your rehearsal, press
the STOP button.
Locating a point slightly before the Auto Punch In point
To locate the playback start point for rehearsal, press the AUTO
PUNCH IN key, then press the LOCATE key.
The FD-8 displays the time (position) stored in the AUTO PUNCH
IN key, and locates the point and stops.
Press the REWIND button to go backward. If you have set the preroll
time as described on page 102, you can locate a point that precedes
the Auto Punch In point by the specified preroll value. For more
information, see “Setting a preroll time” on page 102.
Quick and easy operation for repeated rehearsal
Using the Auto Return function and the Auto Play function enables
you to rehearse repeatedly.
As shown below, set the AUTO RTN START and END points for
Auto Return and Auto Play. In this way, you can repeat rehearsal
easily, while checking the recording level and concentrating on your
performance.
Refer to page 66 for more information on setting the AUTO RTN
START/END points.
When the Auto Return End point is reached, the
FD-8 locates the Auto Return Start point.
Note: If the FD-8 display [Over!] when you turn on Auto
Punch mode, the disk does not have enough free space for
Auto Punch In/Out. You need to erase part of the Program
data, then try again.
