Maintenance/Specifications

Maintenance

Specifications

Cleaning the exterior

* For normal cleaning, use a soft dry cloth

For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off. Then polish with a dry
cloth.
Never use solvents such as alcohol, thinner or benzene, since these will damage the printing and finish of the exterior.

* Mixer section

Connector

: 6mm Phone jack (x 6)

Input Impedance

: 20k

or higher

Reference Input Level : -10dBV

Connector

: 6mm Phone jack (x 2)
: XLR-3-31 type (x 2)

Input Impedance

: 20k

or higher

Reference Input Level : L: -50dBV, M: -30dBV,

H: -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k

or higher

Reference Output Level

: -10dBV

Input Impedance

: 10k

or higher

Reference Input Level : -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k

or higher

Reference Output Level

: -10dBV

Connector

: 6mm Phone jack (x 4)

Input Impedance

: 8k

or higher

Reference Input Level : -20dBV

Connector

: RCA pin jack (x 2)

Load Impedance

: 10k

or higher

Reference Output Level

: -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k

or higher

Reference Output Level

: -10dBV

Connector

: 6mm Stereo Phone jack

Load Impedance

: 16

or higher

Maximum output

: 50mW (at 50

)

: 12kHz +/-15dB (Shelving type)

MID

: 200Hz ~ 5kHz +/- 15dB (Parametric type)

: 80Hz +/- 15dB (Shelving type)

: 20Hz ~ 20kHz (typical)

: 105dB (typical)

* Recorder section

Recording Medium

: External SCSI device
(SCSI-2, asymmetrical transfer)

* Connectable SCSI device: Two (for recording
x1, for backup x 1)

: Internal E-IDE type 2.5 inch
hard disk (optional)

: FDMS-3*

(* Fostex Disk Management System-3)

Normal Mode

: 8 Real track + 16 Additional
track (Sampling Rate: 44.1kHz/
A.D.A.C.*)

Mastering Mode

: 8 Real track + 16 Additional
track (Sampling Rate: 44.1kHz/
16-bit linear)

: 20-bit 64 times over sampling,
delta sigma modulation type

: 20-bit 128 times over
sampling, delta sigma
modulation type

: 44.1kHz/16-bit linear

: Mastering Mode: FDIO-1*

(DAT,

adat)

: Normal Mode: SCSI

(* Fostex Data Input /Output-)1
