Frymaster LOV BIELA14 User Manual
Page 71
2-10
2.4.3.1 Element Assemblies and Hardware cont.
ITEM PART
#
COMPONENT
1
Element
826-2198
200V 7.0 kW (220V 8.5kW used in some export 3-phase 4-wire WYE
units)
√
826-2192 208V
1
7.0 kW
826-2200 220V
1
7.0 kW (240V 8.5kW used in some export 3-phase 4-wire WYE
units)
826-2193 230V
1
7.0 kW
826-2199
230V/400V 7.0/8.5 kW (used in some export 3-phase 4-wire WYE
units)
826-2194 240V
1
7.0 kW
826-2196 480V
1
7.0 kW
√ 2
826-2212
Probe, Temperature RE – includes tie wraps and grommet.
3 816-0681
Grommet,
Probe
4
816-0480
Plug, .375-inch Dome
5 816-0688
Gasket,
Element
6
809-1003
Screw, 10-32 X ⅜-inch Hex Head SS
*
809-0766
Nut, 10-32 Keps Hex Head SS
*
230-4028
Wrench, Element Tube Nut Spanner
7
230-3714
Bracket, Temperature Probe 7.0kW
230-0784
Bracket, Temperature Probe 8.5kW (used in some export 3-phase 4-wire
WYE units)
8
220-0464
Bracket, Lower Spring
9
910-2042
Clamp, Element (Short)
10
230-0781
Clamp, Element (Long)
11
230-4902
Support, Full-Vat Element Rear
12
230-4101
Support, Full-Vat Element Front
13 809-0567
Tie-Wrap,
Metal
14
230-4903
Support, Dual-Vat Element Bottom Rear
15
230-4103
Support, Dual-Vat Element Bottom Front
16
810-3030
Spring, Element Lift Left
810-3131
Spring, Element Lift Right
17
220-0733
Bracket, Lower Spring Mating
* Not illustrated.
√ Recommended parts.
