2-8
2.4.2.1 Left and Right Contactor Box Configurations cont.
NOTES:
Left and right contactor box assemblies are mirror images of one another. With the
exception of the box itself, all components of a left-hand assembly are the same as those in the
corresponding right-hand assembly and vice versa except for the hood relay which occurs in the
right or large box only. The configurations illustrated show all possible components, but a particular
configuration may not have all the components shown.
ITEM PART # COMPONENT
1 106-8658 Box Assembly, Left Contactor
2 106-8660 Box Assembly, Right Contactor
3 221-0482 Cover, Left Hand Contactor Box
4 222-0482 Cover, Right Hand Contactor Box
9 807-0070 Terminal, Ground Lug
√ 5 807-2284 Contactor, 24V 50 Amp Mechanical (Heat)
√ 6 810-1202 Contactor, 24V 40 Amp Mechanical (Latch)
7 807-1683 Relay, Hood 12VDC
8 807-0922 Holder, Bus Fuse
9 807-2278 Fuse, 20 Amp
10 807-0064 Transformer, 480V/120V 150VA
* 221-0610 Bracket, Left Hand Contactor Box Mounting
* 222-0610 Bracket, Right Hand Contactor Box Mounting
* 807-4316 McDonald’s Cordset, 120V 5-Wire
* 807-4317 McDonald’s Cordset, Europe 3-Wire Single Phase
* 807-0012 Relay, Tilt Switch 18 Amp 1/3 HP 24 V Coil
* Not illustrated.
√ Recommended parts.
