2.4.1 Component Boxes cont.
ITEM PART # COMPONENT
1 106-5592 Box Assembly, Component
2 200-3300 Bracket, Component Box Strain Relief
3 806-9495SP Terminal Block
√ 4 807-4346 Relay, 120V DPDT 20A
(used in Canadian models only)
√ 5 807-4482 Relay, Filter 2 Pole 30A DPDT 24VDC
6 807-0037 Terminal, ¼-inch Push-on
7 807-0121 Bushing, Heyco Plastic AB-625-500
8 807-0922 Holder, Buss Fuse HPS Screw Type
9 807-2278 Fuse, 20 Amp
10 810-2446 Plug, Button .50 Heyco Double “D”
√ 11 807-4036 Switch, Power
807-3575 Plug, Carling Switch Hole (used on some models without a switch)
12 807-1947 Plug, Button .875 Dome
13 807-1321 Holder, AGC Panel Mount ¼” Fuse (Some models use item 10 here.)
14 807-1597 Fuse, 3 AMP Slow-Blow
15 810-2445 Plug, Button .625 Heyco Double “D”
16 106-5750 Harness Assembly, RE FV Control
106-5751 Harness Assembly, RE DV Control
√ 17 807-0855 Transformer, 100-120V/12V 20VA
√ 18 807-0800 Transformer, 100-120V/24V 50VA Filter (Used in FV component boxes)
√ 807-4933 Transformer, 120/208/240V/24V 75VA Filter (Used in DV component
boxes)
√ 19 807-2181 Transformer, 100-120V /24V 62VA Filter
√ 20 807-2191 Transformer, 208-240V/12V 30VA
√ 21 807-0979 Transformer, 208-240V/12V 43VA
√ 22 807-2180 Transformer, 100-120V 50VA Filter
23 809-0349 Spacer, 4mm X 6mm Aluminum
24 Interface Board
√ 826-2260 Standard Full or Dual Vat Interface Board (includes sound harness)
* 807-4403 Speaker, 4-Watt SMT
25 220-4723 Guard, Finger w/ switch opening
26 807-4678 Switch, Momentary Flush JIB Reset
27 230-5038 Guard, RE Box Switch
28 816-0217 Paper, Insulating Terminal Block
29 810-0045 Bushing, .875 Diameter 11/16”
30 200-6654 Brace, Component Box
√ 31 807-4346 Relay, DPDT 20A 120V (used for control power reset in right hand boxes
only in domestic and Canadian units)
807-4770 Relay, DPDT 20A 240V (used for control power reset in right hand boxes
only in international units; some international units have one located in
each control box)
32 807-2659 Switch, Momentary (used to reset control power; located in box over JIB
only.)
* 826-2249 RE Hood/Ansul Interlock Kit (includes terminal block, wires and connectors)
* Not illustrated.
√ Recommended parts.
