6. DATA TRANSFER
6-5
6.2 Uploading, Downloading Data
You can upload/download waypoints, routes, marks and lines from/to a PC,
through the DATA 4 port at the rear of the display unit. Note that radar and
sounder data cannot be uploaded or downloaded.
6.2.1 Setting communication software on the PC
The communication format (RS-232C) with the PC is as follows:
Baud Rate: 4800 bps
Character Length: 8 bits
Stop bit:
1 bit
Parity: None
X Control:
XON/XOFF (fixed)
The following data can be downloaded/uploaded between a PC and this
equipment:
•
Waypoint data (In alphanumeric order)
•
Route data (In order of route number)
•
End of sentence
Note 1: There are two kinds of data for route data: route data and route
comment data.
Note 2: DGPS position fix is not available when uploading or downloading data.
Note 3: Wiring information appears on the UPLOAD or DOWNLOAD menu.
6.2.2 Uploading or downloading data
1. Connect the PC to the equipment.
2. Press the [MENU] key to show the main menu.
3. Press the SYSTEM CONFIGURATION soft key.
4. Press the DATA TRANSFER soft key.
5. Press the UPLOAD/DOWNLOAD DATA soft key.
6. Press the DOWNLOAD WPT/ROUTE TO PC or UPLOAD WPT/ROUTE
FROM PC soft key.
UPLOAD
EDIT
UPLOAD
SELECT
BPS
RETURN
DOWN-
LOAD
EDIT
DWLOAD
SELECT
BPS
RETURN
▲ ▲
WAYPOINT & ROUTES OFF
MARKS & LINES OFF
WIRING INFORMATION
DISPLAY UNIT PC: DSUB9
TxD >1>-WHITE-<2RxD >2>-BLUE -<3RD-A >3>-YELLOW
RD-B >4>-GREEN
+12V >5>-RED
EXT BUZZ >6>-BLACK
GND >7>-SHIELD-<5
RS232C SETTING
• 4800BPS,
• 8BIT,
•1STOP BIT,
• PARITY NONE,
• CONTROL Xon/Xoff
WAYPOINT & ROUTES OFF
MARKS & LINES OFF
WIRING INFORMATION
DISPLAY UNIT PC: DSUB9
TxD >1>-WHITE-<2RxD >2>-BLUE -<3RD-A >3>-YELLOW
RD-B >4>-GREEN
+12V >5>-RED
EXT BUZZ >6>-BLACK
GND >7>-SHIELD-<5
RS232C SETTING
• 4800BPS,
• 8BIT,
•1STOP BIT,
• PARITY NONE,
• CONTROL Xon/Xoff
Upload and download menus
