APPENDIX
A-2
GENERAL
SETUP
NAV
SOURCE
SETTINGS NAV
OPTION
SYSTEM
CONFIGURATION
POSITION SOURCE
(FURUNO BB GPS, GP, LC, ALL)
SPEED AVERAGING (0-9999 seconds, 60 seconds)
LOCAL TIME OFFSET (-13:30-+13:30 hr, 00:00)
TEMP CALIBRATION (-40 ° F - +40 ° F, 0 ° F)
DEPTH CALIBRATION (-15 - +90 ft, 0 ft)
Page 1
Page 2
1
2
GPS
SENSOR
SETTINGS
TD SETUP
LOCAL TIME OFFSET (-13:30-+13:30, 00:00)
GEODETIC DATUM (WGS-84, OTHERS: See page A-10.)
POSITION SMOOTHING (0 - 999 seconds, 0 seconds)
SPD/CSE SMOOTHING (0 - 999 seconds, 5 seconds)
GPS SPEED AVERAGING (0 - 999 seconds, 60 seconds)
LATITUDE OFFSET (0.000 - 9.999’N(S), 0.000’N)
LONGITUDE OFFSET (0.000 - 9.999’W(E), 0.000’E)
DISABLE SATELLITE (Max. 3)
LATITUDE (45
°
35.000’N)
LONGITUDE (125 ° 00.000’W)
ANTENNA HEIGHT (0 - 999 m, 5 m)
GPS FIX MODE (2D, 2D/3D)
COLD START (YES, NO)
LORAN-C GRI (9940: 11-27 (US west coast))
CORRECTION 1 (-999.9-+999.9
µ s, 000.0 µ s)
CORRECTION 2 (-999.9-+999.9
µ
s, 000.0
µ
s)
DECCA CHAIN (01: R-G (S Baltic))
CORRECTION 1 (-99.99-+99.99 lane, 00.00 lane)
CORRECTION 2 (-99.99-+99.99 lane, 00.00 lane)
GPS STATUS soft key
(Displays status of GPS satellites.)
KEY BEEP (ON, OFF)
LANGUAGE (ENGLISH, OTHERS)
RANGE UNIT
(nm, kt; km, km/h; sm, mph; nm&yd, kt; nm&m, kt; km&m, km/h; sm&yd, mph)
TEMPERATURE UNIT (
° C, ° F)
DEPTH UNIT (m, ft, fa, pb)
TEMPERATURE SOURCE (ETR, NMEA)
DEPTH SOURCE (ETR, NMEA)
RESET TRIP LOG (YES, NO)
LAT/LON DISPLAY
(DD
°
MM. MM’
DD ° MM. MMM’
DD
°
MM. MMMM’
DD
°
MM" SS.S")
TD DISPLAY (LORAN C, DECCA)
SPEED (SOG, STW)
POSITION DISPLAY (LAT/LON, TD)
TIME DISPLAY (12 HOURS, 24 HOURS)
INFRARED REMOTE MODE (A, B, C, D)
RANGE & BEARING MODE
(GREAT CIRCLE, RHUMB LINE)
BEARING READOUT (TRUE, MAGNETIC)
MAGNETIC VARIATION (AUTO 07.0
°
W, MANUAL)
WAAS SETUP soft key
(Only when GPS-320B is connected.)
WAAS MODE (On, Off)
WAAS SEARCH (Auto, Manual)
WAAS ALARM (On,. Off)
CORRECTION DATA SET (02)
