ix
Features
The 1800C/1900C series of radars and video plotters work within our new product-network
system called the “NavNet.” Each product has an IP address to communicate with NavNet
compatible products within the network, using TCP/IP protocol through an Ethernet
10BASE-T network.
The main features are as follows:
•
The 1800C/1900C series of radars and video plotters consists of the following models:
Model Output Range
Radar
Antenna
Marine Radar Model 1823C 2.2 kW 24 rpm 1.5 ft, Radome
Marine Radar Model 1833C 4 kW 36 nm 2 ft, Radome
Marine Radar Model 1933C 4 kW 48 nm 3.5 ft, Open
Marine Radar Model 1943C 6 kW 64 nm 4 ft, Open
Marine Radar Model 1953C 12 kW 72 nm 4/6 ft, Open
Color Video Plotter GD-1900C — — —
•
Bright 10.4” screen visible even under direct sunlight.
•
User friendly operation with combination of discrete keys, soft keys, alphanumeric keys
and trackball.
•
Accepts FURUNO and Nav-charts™ (NAVIONICS) charts, or C-MAP NT/NT+ charts
(C-MAP), depending on specification.
All names mentioned above are registered trademarks of their respective
companies.
•
Fast chart redraw.
•
Built-in NavNet interface circuit board.
•
Video input (video recorder, CCD device, etc.) available with installation of optional PIP
Board.
•
12-channel GPS Receiver GP-310B with highly accurate position fixing optionally
available, GP-320B with WAAS capability.
•
User programmable function keys.
•
Video sounder picture available with connection of the optional Network Sounder
ETR-6/10N or ETR-30N.
•
Connected the optional facsimile receiver FAX-30 receives facsimile pictures and navtex
messages transmitted from facsimile and navtex stations.
