FUJITSU T5120 - Manual (Page 19)

SPARC Enterprise T5120 and T5220 Servers Site Planning Guide 7
Maximum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(8 core, 1.6 GHz processor, with sixteen 4 GB FBDIMMs, 8 HDDs, 6 PCIe I/O cards)
Idle input power 471.5 W 440.4 W
Peak input power running SpecJBB 807.4 W 754.1 W
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(4 core, 1.2 GHz processor, with four 1 GB FBDIMMs, no HDDs, no PCIe I/O cards)
Idle input power 194.0 W 181.2 W
Peak input power running SpecJBB 220.0 W 205.5 W
TABLE 8 SPARC Enterprise T5220 Server (16-Disk Capable) Power Specifications
General Specifications AC Input Models DC Input Models
Operating input voltage range
(input voltage tolerance +/- 10%) 100 to 240 VAC,
50-60 Hz -48 to -60 VDC
Maximum operating input current
Maximum operating input current At 100 VAC: 9.9A
At 200 VAC: 4.9A At -48 VDC: 21.9A
Maximum operating input power At 100 VAC: 938.5 W At -48 VDC: 876.6 W
Maximum heat dissipation 3202.2 BTU/hour
(3378.5 KJ/hour) 2991.1 BTU/hour
(3155.7 KJ/hour)
Maximum standby power 10.1 W 9.4 W
Maximum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(8 core, 1.6 GHz processor, with sixteen 4 GB FBDIMMs, 16 HDDs, 6 PCIe I/O cards)
Idle input power 546.8 W 510.7 W
Peak input power running SpecJBB 901.5 W 842.0 W
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(4 core, 1.2 GHz processor, with four 1 GB FBDIMMs, no HDDs, no PCIe I/O cards)
Idle input power 194.0 W 181.2 W
Peak input power running SpecJBB 220.0 W 205.5 W
TABLE 7 SPARC Enterprise T5220 Server (8-Disk Capable) Power Specifications
