6 SPARC Enterprise T5120 and T5220 Servers Site Planning Guide • July 2009
TABLE 6 SPARC Enterprise T5120 Server (8-Disk Capable) Power Specifications
General Specifications AC Input Models DC Input Models
Operating input voltage range
(input voltage tolerance +/- 10%) 100 to 240 VAC,
50-60 Hz -48 to -60 VDC
Maximum operating input current
Maximum operating input current At 100 VAC: 7.3A
At 200 VAC: 3.7A At -48 VDC: 16.3A
Maximum operating input power At 100 VAC: 697.4 W At -48 VDC: 651.4 W
Maximum heat dissipation 2379.5 BTU/hour
(2510.5 KJ/hour) 2222.6 BTU/hour
(2344.9 KJ/hour)
Maximum standby power 9.2 W 8.6 W
Maximum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(8 core, 1.4 GHz processor, with sixteen 4 GB FBDIMMs, 8 HDDs, 3 PCIe I/O cards)
Idle input power 419.2 W 391.5 W
Peak input power running SpecJBB 662.4 W 618.7 W
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(4 core, 1.2 GHz processor, with four 1 GB FBDIMMs, no HDDs, no PCIe I/O cards)
Idle input power 187.0 W 174.7 W
Peak input power running SpecJBB 200.0 W 186.8 W
TABLE 7 SPARC Enterprise T5220 Server (8-Disk Capable) Power Specifications
General Specifications AC Input Models DC Input Models
Operating input voltage range
(input voltage tolerance +/- 10%) 100 to 240 VAC,
50-60 Hz -48 to -60 VDC
Maximum operating input current
Maximum operating input current At 100 VAC: 8.9A
At 200 VAC: 4.4A At -48 VDC: 19.7A
Maximum operating input power At 100 VAC: 844.4 W At -48 VDC: 788.7 W
Maximum heat dissipation 2881.1 BTU/hour
(3039.7 KJ/hour) 2691.1 BTU/hour
(2839.3 KJ/hour)
Maximum standby power 10.1 W 9.4 W
