SPARC Enterprise T5120 and T5220 Servers Site Planning Guide 5
Power Source Requirements
Both the SPARC Enterprise T5120 and T5220 servers have two autoranging power
supplies. To ensure redundant operation of the power supplies, connect the two
power cords to separate circuits.
Server models that run on DC input power require that you build power cables and
connect to DC input power as specified in the SPARC Enterprise T5120 and T5220
Server Installation Guide.
Use the specifications only as a planning guide. For more precise power values, make
power measurements on your specific server configuration using your planned
workload. Refer to one of the following tables based on the model of your server.
TABLE 5 SPARC Enterprise T5120 Server (4-Disk Capable) Power Specifications
General Specifications AC Input Models DC Input Models
Operating input voltage range
(input voltage tolerance +/- 10%) 100 to 240 VAC,
50-60 Hz -48 to -60 VDC
Maximum operating input current
Maximum operating input current At 100 VAC: 7.0A
At 200 VAC: 3.5A At -48 VDC: 15.4A
Maximum operating input power At 100 VAC: 660.3 W At -48 VDC: 616.8 W
Maximum heat dissipation 2253.0 BTU/hour
(2377.1 KJ/hour) 2104.5 BTU/hour
(2220.3 KJ/hour)
Maximum standby power 9.2 W 8.6 W
Maximum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(8 core, 1.6 GHz processor, with sixteen 4 GB FBDIMMs, 4 HDDs, 3 PCIe I/O cards)
Idle input power 381.5 W 356.4 W
Peak input power running SpecJBB 615.3 W 574.7 W
Minimum Server Configuration Specifications
Under Nominal Temperature and Voltage Conditions
(4 core, 1.2 GHz processor, with four 1 GB FBDIMMs, no HDDs, no PCIe I/O cards)
Idle input power 187.0 W 174.7 W
Peak input power running SpecJBB 200.0 W 186.8 W
