FS-C Functions
62 FS-C Portable DTE Recorder
Setting Up Master and Slave FS-C
1.
Connect the camcorder to the master FS-C,
DV I/O
connector
using the supplied FireWire cable.
2. Master
Power on unit.
Go to the
HDD Mode
menu screen and enable
USE EXT FS-C
.
3.
Connect the FS-Cs through the units
Computer I/O
connectors
using a 6-pin to 6-pin FireWire cable.
4. Slave
Power on the unit
Go to the
HDD Mode
screen and enable
DD DRIVE
.
5. Master
Begin recording or playback using the master FS-C.
Use DD Drive Mode when Connecting to a PC
It is important to take the master FS-C out of USE EXT FS-C
mode before attempting to connect to a computer.
To do this, select DD DRIVE from the HDD Mode screen.
This returns use of the unit to hard disk mode.
STOP 1 - 001
COUNTER
00 : 00 : 00 : 00
DISK 1 000min
TAPE DISP LOCK
CONNECT
COMPUTER THEN
ENABLE BYPASS
SUCCESS
EXIT
Master FS-C Slave FS-C
4
3
2
1
