39
Model PDS4229W
Screen size 42" wide screen: 92.0 cm (W) x 51.8 cm (H) (105.6 cm diagonal)
36.2 inch (W) x 20.4 inch (H) (41.6 inch diagonal)
Aspect ratio 16:9 (wide)
Weight 28.5 kg / 62.8 lbs
Outer dimensions 103.5 (W) x 64.0 (H) x 8.5 (D) cm / 40.7 (W) x 25.2 (H) x 3.3 (D) inch
Power supply 100–240 VAC 50/60 Hz
Power consumption 3.5 A (800 VA: Power ON, instantaneous power when outputting picture)
Screen dimensions 92.0 (W) x 51.8 (H) cm / 36.2 (W) x 20.4 (H) inch
Number of pixels 852 (H) x 480 (V)
Display modes Video, S-Video input: Normal/Wide1/Wide2/Zoom1/Zoom2
Component Video input: Normal/Wide1/Wide2/Zoom1/Zoom2
RGB-PC: Normal/Wide/Zoom
Decoder: Normal/Wide1/Wide2/Zoom1/Zoom2
Colors 16.77 million (for each of 256 RGB gradations)
External equipment terminals
Video input terminals Video input 1 BNC terminal 1 Vp-p/75
Ω
S-video input 1 S terminal Y: 1 Vp-p/75
Ω
C: 0.3 Vp-p/75
Ω
Component video input (color difference input) 3 BNC terminals Y: 1 Vp-p/75
Ω
Pb/B-Y: 0.7 Vp-p/75
Ω
Pr/R-Y: 0.7 Vp-p/75
Ω
Applicable systems NTSC/PAL/SECAM/PAL60/4.43NTSC
PC input terminal RGB input terminal mD-sub, 3 rows, 15-pin
Picture signal: 0.7 Vp-p/75
Ω
Synchronization signal: TTL level
Control terminal 1 RS-232C connector (D-sub 9-pin)
Operating conditions Temperature: 0 to 40
°
C / 32 to 104
°
F
Humidity: 20 to 90 %
Accessories 1 remote control, 2AA batteries, 1 instruction manual, 1 power cable, 2 ferrite cores
SPECIFICATION
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Regulation PDS4229W
• UL, CSA Safety: UL1950/CSA C22.2 No.950
EMC: FCC Part 15 Class A, ICES-003 Class A
• CE Safety: EN60950 1992, A1: 1993, A2: 1993, A3: 1995, A4: 1997
EMC: EN55022 1994, Class A
EN61000-3-2 1995
EN61000-3-3 1995
EN55024
1998
EN61000-4-2 1995
EN61000-4-3 1996
EN61000-4-4 1995
EN61000-4-5 1995
EN61000-4-6 1996
EN61000-4-8 1993
EN61000-4-11 1994
• AS Safety: IEC60950 A1/A2/A3/A4
EMC: AS/NZS 3548
• Specifications and external appearance may be change for the sake of improvement.
• is a worldwide trademark of Fujitsu General Limited and is a registered trademark in Japan, the U.S.A. and other countries or areas.
