FACTORY SETTINGS
This display can store parameter settings for four additional signals for RGB.
To do this, select a desired signal and follow the instructions in “Adjusting Screen Position and Size” on P. 26–27 to adjust the
parameters. When you finish, the settings will be automatically stored. Thus, when the display receives that signal, pictures will be
displayed in accordance with the settings you most recently selected.
Main corresponding signals (RGB-PC mode)
• With the 800 x 600 and 1024 x 768 modes, pictures of reduced size are displayed on the screen, using size reduction and interpolation. Note also
that on-screen information is also displayed in reduced size.
• “Out of range” appears if the display receives a signal whose characteristic does not fall within the display’s permissible range.
• You can check input signals through “Information” on the FEATURES Menu screen. (See P. 35.)
• All terms (i.e., company and product names) used in this document are trademarks or registered trademarks.
Main corresponding signals (Comp.Video, Decoder mode)
852 x 480 31.72 59.97 When a dedicated graphics card is used
640 x 480 31.47 59.94 VGA
640 x 480 37.86 72.81 VGA 72 Hz
640 x 480 37.50 75.00 VGA 75 Hz
640 x 480 43.27 85.01 VGA 85 Hz
720 x 400 31.47 70.09 VGA 400 lines
800 x 600 37.88 60.32 SVGA 60 Hz
800 x 600 48.08 72.19 SVGA 72 Hz
800 x 600 48.88 75.00 SVGA 75 Hz
800 x 600 53.67 85.06 SVGA 85 Hz
1024 x 768 48.36 60.00 XGA 60 Hz
1024 x 768 56.48 70.07 XGA 70 Hz
1024 x 768 60.02 75.03 XGA 75 Hz
640 x 480 35.00 66.67 MAC 13RGB
848 x 480 31.02 60.00
640 x 480 15.73 59.94 60 fields
640 x 480 15.63 50.00 50 fields
640 x 400 31.50 70.15 NEC 31 kHz
Signal Display (dots x lines) Horizontal frequency (kHz) Vertical frequency (Hz)
15.73 59.94 SDTV 480I
15.63 50.00 SDTV 576I
31.47 59.94 SDTV 480P
31.25 50.00 SDTV 576P
45.00 60.00 HDTV 720P
37.50 50.00 HDTV 720P
33.75 60.00 HDTV 1080I
28.13 50.00 HDTV 1080I
Horizontal
frequency (kHz)
Signal
Vertical
frequency (Hz)
Main corresponding signals (Video, S-Video mode)
15.73 59.94 NTSC
15.63 50.00 PAL
15.63 50.00 SECAM
15.73 59.94 PAL60
15.73 59.97 4.43NTSC
Horizontal
frequency (kHz)
Signal
Vertical
frequency (Hz)
* With some input signals, “Out of range” may appear even when the horizontal and vertical frequencies are within their permissible ranges. Make
sure that the vertical frequency of the input signal is 85 Hz or less for SVGA and 75 Hz for XGA.
In the Comp.video and Video/S-video modes, the display has been factory-set as follows for different input signals:
