5.3 Replacing the Pick Roller(3)
1 2 3
14. Reset the pick counter.
When turning on the power, check that the scanner is connected to your PC.
Open the [Scanners and Cameras] from the [Control Panel] of your PC.
Open the [Properties] of [fi-5110Cdj] from the [Scanners and Cameras].
The [Properties of fi-5110Cdj] dialogbox is displayed.
Click the "Device Set" tab.
The following panel appears.
After clicking the [Clear] button beside "Pick Roller" in "Page Counter", click the [OK] button.
The following panel appears.
Click the [OK] button.
This returns the pad counter to "0".
