5.1 Consumable and Replacement Cycle (5)
1 2 3 4 5
The following message may appear while you use the scanner:
Replace consumables when this message is displayed.
After clicking the [Ignore] button, this message will disappear and scanning will continue.
Please replace the consumable as soon as possible.
As a default, this message appears again after 100 scans. If you do not wish this message to display, click
the [ this message not display again].
To stop scanning and replace the consumable, click the [Cancel] button.
Replacement information is given in the following:
Pad ASSY: See "
5.2 Replacing the Pad ASSY "
Pick Roller: See " 5.3 Replacing the Pick Roller "
