Symptom 11 : Paper jams occur frequently
Back
Do the documents satisfy the
conditions described in " 7.2 Document
Quality "?
No
Use the document that satisfy the
requirements.
For details on requirements, see " 7.2
Document Quality ".
Yes
Is there any debris in the ADF?
Yes
Clean the ADF or remove debris from
the ADF.
For details on how to clean the ADF,
see " 4.3 Cleaning the Inside of the
Scanner " .
No
Are all the consumables (Pick roller
and Pad ASSY) installed correctly?
No
Correctly install the consumable (Pick
roller and Pad ASSY), if needed.
For details on how to install the
consumables, see " 5 REPLACING
CONSUMABLES " .
Yes
Is any of consumables (Pick roller, Pad
ASSY) dirty?
Yes
Clean the dirty consumable.
For details on how to clean the
consumables, see " 4 DAILY CARE ".
No
Is any of consumables (Pick roller and
Pad ASSY) worn out? (Check the
consumable counter)
Yes
Replace the consumable, if needed.
For details on how to replace the
consumables, see " 5 REPLACING
CONSUMABLES ".
No
If you cannot solve the problem after
taking measures, check the items in
" 6.4 Items to Check Before Contacting
the Agent Where You Bought the
Scanner " and contact the dealer or an
authorized FUJITSU service provider.
