AP-11
APPENDIX 4 PARTS LIST,
PARTS LOCATION
This chapter shows only the modules/components/parts that can be replaced in shipboard main-
tenance (IMO A.694(17)/8.3.1). Main modules are shown on the parts location illustrations, which
follow the parts list.
Parts List
Model DOPPLER SONAR DS-60
Unit
UNIT PRINTED CIRCUIT BOARD/ CODE NO.
ASSY. TYPE
DISPLAY UNIT DS-600
MAIN BOARD 26P0006 001-098-030
PNL BOARD 26P0007 001-098-050
MCN BOARD 02P6345 -
LCD NL6448BC26-22F 000-171-704-10
DISTRIBUTOR UNIT DS-610
MAIN BOARD 66P3950 001-090-660
I/F BOARD 66P3951 001-090-650
CONT BOARD 66P3952 001-090-630
ZNR BOARD 66P3953 001-090-610
TRANSCEIVER UNIT DS-620
MAIN BOARD 66P3960 001-097-930
TX BOARD 66P3961 001-090-720
PWR BOARD 66P3962 001-090-690
FIL BOARD 66P3964 001-090-700
JUNCTION BOX DS-640
JTB BOARD 66P3970 001-090-800
REMOTE CONTROLLER RD-501, DIMMER CONTROLLER RD-502
DISPLAY UNIT DS-600
DISTRIBUTOR UNIT DS-610
TRANSCEIVER UNIT DS-620
JUNCTION BOX DS-640
REMOTE CONTROLLER RD-501
DIMMER CONTROLLER RD-502
2010/3
RMT BOARD 26P0012 001-076-930
