3. BERTHING DISPLAY

3-4

Predicted track

The predicted track feature shows estimated position of your ship at the end of the se-
lected time interval. (See section 3.3.4 for the procedure.) The estimated position is
calculated from the reference point and stern speeds taken from the ground and water
tracking speed data. The marker is purple, hollow and dashed to distinguish it from the
own ship marker and the past track markers.

3.3.2

How to select the type of track to display

1. Press the MENU/ESC key to open the menu.
2. Select [Ship’s Track] then press the ENT key.

3. Select the type of track to display then press the ENT key. Select [OFF] to hide all

tracks.

4. Press the DISP key to close the menu.

Predicted track
marker (purple)

Predicted track

Own ship marker
