4.1 Mounting Requirements
C141-E234
4-3
4.1.2 Mounting
orientations
The permissible orientations of the HDD are shown in Figure 4.2, and the tolerance of the angle is
±5° from the horizontal plane.
(a) Horizontal –1
(b) Horizontal –2
(c) Vertical –1
(d) Vertical –2
(e) Upright mounting –1
(f) Upright mounting –2
Figure 4.2
HDD orientations
4.1.3
Notes on mounting
Damage
Never remove any labels from the drive or deface them in any way.
Direction of gravity
