CHAPTER 4
Installation Requirements
4.1 Mounting
Requirements
4.2
Power Supply Requirements
4.3 Connection
Requirements
This chapter describes the environmental, mounting, power supply, and connection requirements.
4.1 Mounting
Requirements
4.1.1 External
dimensions
Figures 4.1 show the external dimensions of the HDD and the location of the holes for the HDD
mounting screws.
