Frymaster FOOTPRINT RE80 - Manual (Page 57)

2-28
NOTES: Left and right contactor box assemblies are mirror images of one another. With the exception of the
box itself, most components of a left-hand assembly are the same as those in the corresponding right-hand
assembly and vice versa. The configuration illustrated shows most possible components, but a particular
configuration may not have all the components shown.
ITEM PART # COMPONENT
Contactor Box Assemblies (for reference only)
106-9967 17 kW, 3-wire, Left
106-9966 17 kW, 3-wire, Right
106-9756 21kW, 3-wire, Left
106-9755 21kW, 3-wire, Right
108-0427 17 kW, 4-wire, Left
108-0426 17 kW, 4-wire, Right
108-0037 21kW, 4-wire
108-1861 17kW, Single
108-0684 21kW, Single
108-0868 21kW, 4-wire, Single, Export
Contactor Box Parts
1 106-9601 Stud Assembly, Left Contactor Box
* 106-9600 Stud Assembly, Right Contactor Box
2 106-9735 Harness, 6-pin
3 106-9736 Harness, 9-pin
4 200-6648 Bracket, Fuse Block
5 200-6809 Bracket, Ground Lug Holder
6 221-5553 Cover, 21kw Contactor Box
* 220-5103 Cover, 17kw Contactor Box
7 807-0070 Terminal Lug
8 807-0501 Fuse Block
9 807-2283 Contactor, 63 AMP, Mechanical, 24V Coil (21kw)
* 807-2284 Contactor, 50 AMP, Mechanical, 24V Coil (17kw)
10 807-3610 Terminal Block
* 807-1268 Terminal Block, Splicer Single (4-wire)
11 807-4017 Fuse, 50 AMP, 300 VDC
12 810-1202 Contactor, 40 AMP, 3-pole
13 108-1786 Harness, Contactor Box
14 220-6545 Door, Fuse Access
15 810-0519 Hinge, Fuse Access
* 220-5484 Mount, Contactor Box (2 per box)
* Not illustrated. ** Full Vat has three relays 826-1562, Dual-Vat has six relays.
