2-6
2.2.2 Cabinets, Bases, Braces, and Associated Parts cont.
ITEM PART
#
COMPONENT
Cabinet Sides
4
231-4896
Side, Stainless Steel, Left
5
232-4896
Side, Stainless Steel, Right
221-5073
Side, Painted, Left
222-5073
Side, Painted, Right
221-5170
Side, Inner, Left (x5 and x6 units)
222-5170
Side, Inner, Right (x5 and x6 units)
6
220-5983
Divider (multi-vat units)
Post
7
220-5112
Front (all x2, x4, x5, x6 units and x3 filter cabinet)
8
220-2250
Front (x3 non-filter cabinet)
9 220-5032
Rear,
Standard
* 220-5210
Rear,
Church’s/Popeye’s
10
220-4937
Brace, Frypot Locating
*
220-5979
Brace, Pump Motor Support
*
220-5490
Mount, Contactor Box (x1)
11
220-4860
Bracket, Lower Spring
12
Brace, Upper Cabinet, Front
220-0274
x1
200-9590
x2, x5 (1)
220-0608
x3, x5 (1), x6 (2)
x4
13
Brace, Upper Cabinet, Rear
220-0274
x1
220-1809
x2, x3, x4, x5, x6
14
Brace, Lower Cabinet, Front
220-5267
x1
220-4999
x2, x3 (1), x5 (1)
200-8100
x3 (1), x4 (2), x5 (3), x6 (4)
Brace, Lower Cabinet, Rear
220-4570
x2
220-4569
x3
15
824-1966
Bridge, Filter
16
Filter Pan Lid (see next section)
17
221-2576
Rail, Left
18 222-2576
Rail,
Right
19
823-3347
Frame, Slide Base
20 823-6450
Bracket,
Disconnect
*
826-1115
Leg Assembly (includes 810-3168)
*
826-1118
Caster Assembly with Brake (includes 810-0357)
*
826-1117
Caster Assembly without Brake (includes 810-0356)
*
826-0900
Chain Restraint Kit (required for all caster installations)
* Not illustrated.
