Frymaster FOOTPRINT RE80 User Manual
Page 55
2-26
2.9.1 Component Boxes
ITEM PART
#
COMPONENT
Component Box Assemblies (for reference)
106-9730 208/240V,
Filter
106-9732 208/240V,
Non-filter
108-0279 220/250V,
Filter
108-0278 220/250V,
Non-filter
108-0420 480V,
Filter
108-0421 480V,
Non-filter
108-0330
480V, no switch, no basket lift
Component Box Parts
1 106-6666 Interface
Board
* 106-9930 Harness,
Filter
* 106-9965 Harness,
Non-filter
2 220-4465 Panel,
Switch
3 230-4346 Guard,
Switch
4 807-4036 Switch
5
220-5805
Standoff, Relay, Filter
6
807-4114
Relay, 24VAC Coil, Filter
7
807-0922
Holder, Screw-Type Buss Fuse
* 807-4765 Harness,
Control
8
809-0963
Standoff, 6-32, ¼” x 2.00 NP
9
810-1164
Block, Screwless Terminal
10 823-6745 Box,
Component
11
807-2278
Fuse, 20 Amp
12 807-1597 Fuse,
Slo-blo, Filter (220-250V)
13
Transformers
807-0979 208/240V,
12V
807-0680 208/240V
807-2180
208/240V, 24V, 50VA
807-2191 V&F,
208/230/240V,
12V
807-0800
120V, 50/60 Hz-24V, 50VA
807-0855
120V, 50/60 Hz-12V, 20VA
807-3892 440/480V
to
12/24V
14
810-3141
Sound Device, SMT
*
108-0273
Sound Device, KFC
*
Not
illustrated.
