Section 9: Board Level Diagnostics

The purpose of this section to provide the User with specific Board Level Diagnostic
procedures for Board Errors and Sensor Testing for the C10/M10 Card Printer.

Sensor Testing

Step Procedure

Check the voltage to determine if a Sensor is working.

a. Test the voltage of each Sensor using ground (GRD = Chassis) to the

correct pin on each connector. See the Sensor Location and Voltages
table on the next page.

b. Block a Slot Sensor with a card.

c. Cover a reflective Sensor with a card.

Reviewing the Motor Voltages (when active)

Use this table as a reference tool for Board Level Diagnostics.

Motor Location

Pin VDC

Print Drive Stepper

J22

Print Headlift

J27

17.0

Card Feed

J28

Ribbon Drive

J25
