System expansions
A26361-K680-Z122-1-7619, Edition 1 45
2 1
► Slide the slide-in module into the casing (1).
► Secure the slide-in module with the screws (2).
► Fit the data and power supply connectors to the floppy disk drive.
► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see
also the technical manual for the mainboard).
► Attach the front panel (see "Attaching the front panel" chapter).
► Close the casing (see "Closing the casing" chapter).
i
It may be necessary to modify the entry for the drive in the BIOS Setup .
Installing or removing the hard disk drive
► Open the casing (see "Opening the casing" chapter).
► Remove the front (see "Removing the front panel" chapter).
