Preparing for use
8 A26361-K680-Z122-1-7619, Edition 1
Connecting the mouse
Depending on the equipment level selected, your workstation will be supplied with a PS/2 mouse or
a USB mouse.
Connecting a PS/2 mouse
►
Connect the PS/2 mouse to the PS/2 mouse port on the workstation.
Connecting USB mouse
►
Connect the USB mouse to the USB port on the workstation.
i
If you do not attach a mouse at the PS/2 mouse port, you can disable the mouse
controller in the BIOS Setup in order to free the IRQ12 for a different application.
Connecting a keyboard
Depending on the selected equipment level, your workstation will be supplied with a standard
keyboard or a USB keyboard.
Connecting standard keyboard
Use the supplied keyboard cable only.
►
Plug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
► Plug the round plug of the keyboard cable into the keyboard port on the workstation.
Connecting USB keyboard
Use the supplied keyboard cable only.
►
Plug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
► Insert the rectangular USB plug of the keyboard cable into the USB port on the
workstation.
