System expansions
A26361-K680-Z122-1-7619, Edition 1 41
Removing an accessible drive
► Open the casing (see "Opening the casing" chapter).
► Remove the front (see "Removing the front panel" chapter).
► Pull the data and the power supply connectors from the desired drive.
► Pull the drive out of the casing.
► If necessary, make the required settings on the remaining hard disk drive.
2
2
1
1
1
1
► Loosen the screws (1).
► Remove the rails from the drive (2).
