System expansions
A26361-K680-Z122-1-7619, Edition 1 33
► Close the casing (see "Closing the casing" chapter).
i
If you have installed or removed a PCI board, please check the relevant PCI slot settings
in the BIOS Setup . If necessary, change the settings. Further information is provided in the
PCI board documentation.
Installing board with clip
► Open the casing (see "Opening the casing" chapter).
2
1
2
► Press on the clip (1) in the direction of the arrow and unhook it.
► Pull off the clip (2).
► Remove the rear slot cover plate from the slot (2).
!
Do not dispose of the cover plate. For cooling, protection against fire and in order to
comply with EMC regulations, you must refit the cover plate if you remove the board.
► Make the required settings for the board.
