23

ENGLISH

NOTE:

Selectable picture format aspect ratios may vary depending on

the input source or broadcast signal.

Picture Size menu also can be displayed by pressing ASPECT

on the remote control.

Natural

In some cases, this image will display the size of standard 4:3 with

a black side bar.

Cinema Wide1 (for 4:3 format programs)

To fill the screen, the right and left edges are extended. However,

the center of the picture remains near its former ratio.

The top and bottom edges of the picture may be hidden.

Cinema Wide2 (for letter box programs)

To fill the width of the screen, it is extended horizontally. However,

it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

Cinema Wide3 (for letter box programs with subtitles)

To fill the width of the screen, it is extended horizontally. However,

it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

Full (for 16:9 source programs)

Full will display the picture at the maximum size.

Native (for PC mode only)

Detects the resolution of the signal of the image and it will be shown

on the screen with same amount of pixels.

NOTE:

Some High Definition and/or Digital broadcasts may not allow

you to change the picture format aspect ratio.

In HDMI or COMPONENT mode with a scanning rate of 720p,

1080i or 1080p (only HDMI), only the Cinema Wide2 and Full

are available.

In PC Mode, only the Natural, Full and Native are available. In

PC Mode (WXGA), only the Full and Native are available.

Using the Blu-ray Disc player

Playing a disc - Standard playback

1

Press POWER on the unit or on the remote, then press

TV/BD to select Blu-ray mode.

2

Place the disc in the disc slot with the label side facing

forward. Hold the disc without touching either of its surfaces,

align it with the guides, and place it in position.
The main menu as shown below will appear.

PANDORA

®

internet radio

Connected

Settings

3

Press C or D to select the disc, then press ENTER.
After a period of time, Chapter 1 of Title 1 on the disc will

begin playback.
On many BD/DVDs, Chapter 1 of Title 1 is an advertisement

or preview of upcoming releases. If you wish, you may press

DISC MENU to bring up the main disc menu. From there, you

can use C, D, B or A to select the “PLAY MOVIE” menu item.

4

To stop playback, press STOP 3 .

5

Press EJECT to remove the disc.
When you eject the disc, you may hear mechanism noise, but

it is not malfunction.

NOTE:

Some discs may take a minute or so to start playback.

If an 8 cm disc is placed into the disc slot and picture playback

or menu display does not begin automatically, press PLAY 1.

A “Prohibited” symbol “ ” may appear at the upper right of the

screen. This symbol means either the feature you tried is not

available on the disc, or the unit cannot access the feature at

this time. This does not indicate a problem with the unit.

If you place a single-faced disc label backwards (i.e. the wrong

way) then “No Disc” will be displayed.

Some playback operations of BDs may be intentionally fixed

by software producers. Since this unit plays BDs according to

the disc content recorded, some playback features may not be

available. Also refer to the instructions supplied with the BDs.

Playing a disc - Special playback

Fast Forward Playback

Press SEARCH 9during normal playback.

Fast forward begins at 2x normal playback speed. Each press of

SEARCH 9cycles the playback speed through 2x, 4x, 8x, 16x,

32x, 64x and 128x.

To resume normal playback, press PLAY 1.

Fast Reverse Playback

Press SEARCH8 during normal playback.

Fast reverse begins at 2x normal playback speed. Each press of

SEARCH8 cycles the playback speed through 2x, 4x, 8x, 16x,

32x, 64x and 128x.

To resume normal playback, press PLAY 1.
