16
Starting setup
The Starting Setup menu appears the first time you turn on
the TV. It will assist you to specify the Air/Cable setting and
program your channels automatically.
IMPORTANT: Make sure that the antenna or cable TV system
connection is made!
1
To turn on the TV, press POWER (POWER indicator on the front
of the unit changes blue. It may take approx. 10 seconds for a
picture to appear on screen.). The starting setup function begins.
Scan Start
This unit has been preset to STORE brightness
This setting does not qualify under ENERGY
STAR V4.0. To reduce brightness and energy
consumption, change setting to ‘HOME’. This
setting does qualify under ENERGY STAR V4.0.
Auto Setup
TV Location Store
: Adjust : Move
Source Cable
2
Press ▲/▼ to select “TV Location”, then press ◀/▶ to select
“Home” or “Store”. This product qualifies for ENERGY STAR
V4.0. in Home mode default setting.
NOTE:
This unit has been preset to Store brightness. This setting
does not qualify under ENERGY STAR V4.0. To reduce
brightness and energy consumption, change setting to
‘Home’. This setting does qualify under ENERGY STAR V4.0.
The device may not conform to the ENERGY STAR V4.0.
standard after Reset is performed or the Backlight is
adjusted.
•
•
3
Press ▲ or ▼ to select “Source”, then press ◀ or ▶ to select
“Cable” or “Air”.
4
Press ▲ or ▼ to select “Scan”, then press ▶ or ENTER.
5
Now the “Auto Setup” starts. After the starting setup is
completed, the TV channel appears on the screen.
• Depending on the reception condition, it may take from 15
minutes to 30 minutes to complete memorizing digital cable
channels. Please be patient.
NOTE:
If you press ENTER in the process of “Auto Setup”, the Starting
Setup stops and changes to the normal screen.
When you make a menu selection, your changes occur
immediately. You do not have to press EXIT to see your changes.
TV operation
1
To turn on the TV, press POWER.
(POWER indicator on the front of the unit changes blue.
It may take approx. 10 seconds for a picture to appear on
screen.)
2
Adjust the volume level by pressing VOL + or – . The volume
level will be indicated on the screen by blue bars. As the
volume level increases, so do the number of bars. If the
volume decreases, the number of blue bars also decreases.
3
Set the Signal Type option to the appropriate position (see
“Air/Cable selection” on page 19).
4
Press the Direct Channel Selection (0-9, –) buttons to
select the channel.
(If you press only the channel number, channel selection will
be delayed for a few seconds.)
•
•
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to select channel 2,
press 2, then press ENTER.
10-99: Press the 2 digits in order. Example, to select
channel 12, press 1, 2, then press ENTER.
100-135: Press the 3 digits in order. Example, to select
channel 120, press 1, 2, 0, then press ENTER.
TO SELECT DIGITAL CHANNELS
Press the first 3 digits, then press the – button, followed by the
remaining number.
Example, to select channel 15-1, press 1, 5, –, 1, then press
ENTER.
If a channel is selected with only audio content, “Audio
Only” will be displayed on the screen.
If a channel is selected with a weak digital signal, “Weak
Signal or Channel not available.” will be displayed on the
screen.
The same program may be available on either an analog
channel or a digital channel. You may choose to watch
either format.
If a channel is selected to which you have not subscribed,
“Digital channel is encrypted” will be displayed on the
screen.
•
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13
VHF
2-13
UHF
14-69
STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)
NOTE:
If a channel with no broadcast is selected, the sound will
automatically be muted.
It may take a few seconds for a digital channel picture to appear
on screen after being selected.
To select the video input source
To view a signal from another device connected to your LCD
TV/BD, such as a VCR player, press INPUT, then press ▲/▼ or
corresponding Number buttons (0-7), then press ENTER. You
can select TV, Video 1, Video 2, Component, HDMI1, HDMI2, PC
or Blu-ray (Built-in) depending on which input jacks you used to
connect your devices.
Input List
[0-7]:Select
0.TV
1.Video 1
2.Video 2
3.Component
4.HDMI 1
5.HDMI 2
6.PC
7.Blu-ray
CH /
Press and release CH / . The channel automatically stops at
the next channel set into memory.
For proper operation, before selecting channels, they should be
set into the memory. See “Memorizing channels” on page 19.
•
•
