27 Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
LOG #3 (SRV2044-703): Place log #3 on the left two grate bars using the notch on the bottom of log #3.
Slide the left edge of log #3 forward until it touches the grate.
LOG #4 (SRV2044-701): Place log #4 into the tab on log #1. The bottom notch of log #4 should sit on the
grate as shown.
NOTCH
3
4
LOG #5 (SRV2044-702):
Place log #5 into the tab in log #1. The “Y” end of log #6 should fi t around the
grate as shown.
5 TAB LOCATOR
TAB LOCATOR
