D. Mantel Projections

Figure 3.3 Clearances to Mantels or other
Combustibles

above

Appliance

1/2 INCH

(13mm)

12 INCHES

(305mm)

TOP FRONT EDGE
OF FIREPLACE

12 INCHES

(305mm)

NON-COMBUSTIBLE

MATERIAL ONLY
