Figure 7-1, Configuration example – HP SL500 (M852x) User Manual
Page 60
Configuring the M8521 Tape Library for the NonStop
S-Series Server
SL500 (M852x) Tape Library Installation and User’s Guide — 541531-006
7 -2
Configuration Overview
For more information on the IOAM enclosure, see the Modular I/O Installation and
Configuration Guide.
Figure 7-1. Configuration Example
Note. The control path is used to control the robot, and the data path is used to control the
tape drive (M8504).
NonStop Modular Rack Tape Library
S-Series (Rear View)
System
IOAM
Enclosure
MSEBs
ServerNet
Switch Board
Fibre Channel
Fiber-optic
Cable
Adapters (FCSAs)
ServerNet
Fiber-optic
Cables
Control
Data
Path
Path
