Page 43
Library Operation
SL500 (M852x) Tape Library Installation and User’s Guide — 541531-006
3- 11
Replacing a Cleaning Cartridge
Replacing a Cleaning Cartridge
Cleaning cartridges have a limited life span. When the usage count exceeds its limit,
you must replace it with a new one.
To replace a cleaning cartridge:
1. Open the door.
2. Remove the expired cleaning cartridge from its reserved slot.
3. Insert the new cleaning cartridge into that slot.
4. Close the tape library door.
5. Wait until the initialization tests complete before performing another task.
Figure 3-8. Manual Release Screw
1. Gripper belt and pulleys
2. Gripper
3. Release screw
