Library Operation

SL500 (M852x) Tape Library Installation and User’s Guide — 541531-006

3 -8

Inserting a Cartridge Into a Tape Drive

Inserting a Cartridge Into a Tape Drive

To manually insert a cartridge into a tape drive:

1. Obtain the VOLID label, location, and tape drive number from the server console.

2. Open the door.

3. Locate the cartridge.

4. Hold the cartridge so that the VOLID is facing you and can be read from right to

left.

5. Insert the cartridge into the tape drive.

6. Close the tape library access door.

Caution. Potential equipment damage. You must insert the cartridge properly or you will
damage the tape drive.

Figure 3-6. Inserting Cartridge Into Tape Drive

1. Cartridge
2. Drive
