72" Rear Discharge Deck Pulley Assembly
NOTES:
1. Torque to 118 ft. lbs.
2. Torque to 65-75 ft. lbs.
3. See ‘‘72", 60" & 54" Rear Discharge Deck Belt Routing/Tensioning’’ on
page 8-8 for belt tensioning.
4. See ‘‘Spindle Assembly—796235X’’ on page 7-34 for breakdown.
5. See ‘‘Spindle Assembly—796680X’’ on page 7-35 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
1 797167 797167 1 72" REAR DISCHARGE DECK BELT
2 110459 110459 1 PULLEY COVER RH
3 110458 110458 1 PULLEY COVER LH
4 781872 781872 1 CS .625-11X1.25 HX G5 Z
5 028118 028118 6 FW .62 X 1.00 X .134 ZN
6 796714 796714 5 6" HB IDLER PULLEY RD
7 600296 600296 1 DECK IDLER SPACER
8 781567 781567 1 NT .500-13 HX G8 ZY NL
9 767962 767962 13 FW .531 X 1.063 X .090 SAE HD ZN
10 770867 770867 2 PLASTIC BUSHING .750X1
11 109549 109549 1 IDLER PIVOT BUSHING
12 109948 109948 1 IDLER ARM W/A
13 781302 781302 1 IDLER SPRING
14 259812 059931 1 SIDE MOUNT CHAIN (13 LINKS)
15 704759 704759 1 FW .500X 1.250X.075 ZNY
16 601779 601779 1 IDLER GUIDE UHMW
17 797910 797910 2 CS .312-18 X1.50FLT SH ZY
18 016972 016972 4 NT .625-11 HX G5 ZNYC
19 016527 016527 15 CS .500-13 X 1.00 HX G5 ZN
20 752386 752386 3 CW .515 X 2.25 X .204 ZN
21 538850 538850 3 DRIVE PULLEY DB-112
22 792002 792002 4 5/16-18 X 3/4" MALE KNOB
23 782474 782474 6 CW .631 X 2.250 X .187 PNT
24 783738 783738 3 CS .625-11 X 3.00 FULL HX G5 ZN
25 796680X 796680 1 REAR DISCHARGE DECK SPINDLE ASSEMBLY
26 796508 796508 1 BLADE, F23.86-L-F-CCW
27 212472 212472 3 KEY 1/4 SQ X 1.00 LONG
28 796722 796722 1 CS .625-11 X 3.00 LH HX G
29 768523 768523 1 FW .343 X .687 X .051/.080 HD ZN
30 058776 058776 1 NT .312-18 HXZY NL
31 796235X 796235 2 SPINDLE HOUSING ASSEMBLY
32 796839 796839 2 BLADE, F23.86-L-F-CW
33 029934 029934 2 CS .625-11 X 3.00 HX G5 ZNYC
