109706 10/08 7-9
66" Side Discharge XR7 Deck Pulley Assembly
NOTES:
1. Torque to 118 ft. lbs.
2. Torque to 67-75 ft. lbs.
3. Apply grease to zerk (see owner’s manual).
4. See ‘‘72", 66" & 54" Side Disch. Deck Belt Routing/Tensioning’’ on page
8-6 for belt tensioning.
5. See ‘‘Spindle Assembly—796235X’’ on page 7-34 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 601528 601528 1 B-SECTION BELT
2 797910 797910 6 CS .312-18 X 1.50 FLT SH ZNYC
3 601434 601434 2 UHMW IDLER SLIDE
4 025007 025007 1 CS .625-11 X 1.75 HX G5 ZNYC
5 347443 347443 1 DECK BELT IDLER GUIDE
6 028118 028118 3 FW .62 X 1.00X.134 ZN
7 781856 781856 1 5.00" IDLER PULLEY
8 373191 059931 1 SIDE MOUNT CHAIN (21 LINKS)
9 781302 781302 1 IDLER SPRING
10 350884 350884 1 DECK IDLER
11 103721 103721 1 RS 66" XR7 PULLEY COVER
12 103739 103739 1 LS 66" XR7 PULLEY COVER
13 016972 016972 2 NT .625-11 HX G5 ZNYC
14 781385 781385 2 6.00" IDLER PULLEY,
15 797449 797449 4 FW .650X1.125X.18 ZNYCG5
16 792002 792002 4 5/16-18 X 3/4"MALE KNOB
17 016527 016527 3 CS .500-13 X 1.00 HX G5 ZN
18 752386 752386 3 CW .515X 2.25X .204 ZN
19 798975 798975 3 B-SEC 6.32 EOD PULLEY
20 705954 705954 12 CS .500-13 X 1.25 HX G5 ZNYC
21 767962 767962 12 FW .531 X 1.063 X .090 SAE HD ZN
22 768523 768523 6 FW .343 X .687 X .051/.080 HD ZN
23 058776 058776 6 NT .312-18 HXZY NL
24 212472 212472 3 KEY 1/4 SQ X 1.00 LONG
25 796235X 796235 3 SPINDLE HOUSING ASSEMBLY
26 798496 798496 3 BLADE, F22.50"-H-F-CW
27 769257 769257 1 FW .656X 1.250X.250 ZNYC
28 782474 782474 5 CW .631 2.250 X .187 PNT
29 029934 029934 3 CS .625-11 X 3.00 HX G5 ZNYC
30 783738 783738 2 CS .625-11 X 3.00 FULL HX G5 ZN
