Hustler Turf Diesel Z - Manual (Page 41)

109706 10/08 5-13
Air Filter Installation
NOTES:
1. Orient the hose clamp on the air filter to engine hose so that it is
accessible for maintenance (See FIG. 4 on page 10-4). Orient the
precleaner cap with the vent notch facing downward and away from the
operator (See FIG. 5 on page 10-4).
2. For tractors with serial numbers prior to 08070401, use 706531
(Grommet).
3. Includes Item 18 (785261 Main Filter Element). Item 17 (785279 Safety
Element) must be ordered separately.
4. Service part includes decals. See “Tractor Decals” on page 9-2.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 782763 782763 1 DONALDSON AIR CLEANER
2 079186 079186 2 CS .312-18X1.250 HX G5
3 768523 768523 9 FW .343X.687X.051/.080H
4 785741 785741 1 BAND AIR CLEANER MOUNT
5 795138 795138 1 AIR FILTER INDICATOR
6 057661 057661 5 HOSE CLAMP
7 601359 601359 1 HOSE FRESH AIR INTK HDZ
8 601360 601360 1 HOSE INTAKE HDZ
9 034272 034272 5 NT .312-18 HX G5 ZNYC
10 016253 016253 3 CB .312-18X .750 FUL ZN
11 036236 036236 2 CS .312-18X1.000 HX G5
12 775353 775353 1 ENGINE CENTRIFICAL PREC
13 794644 794644 2 GM 1.50 X 2.12 X 1.75
706531 706531 1 GM 1.12X1.75X1.37X.12
14 549394 109279 1 PANEL W/A A/C MNT HDZ
15 109341 109341 1 SCREEN RS W/A HDZ
16 791384 791384 1 LATCH HEAVY DUTY SWELL
17 785279 785279 1 SAFETY AIR FILTER ELEMENT
18 785261 N/A 1 MAIN AIR FILTER ELEMENT
3
2
4
