109706 10/08 5-17
Engine Cover Installation
NOTES:
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601363 601363 1 HOOD HDZ
2 767954 767954 2 FW .406X .812 X.060 SAE
3 068551 068551 8 NT .250-20 HXZY NL
4 712927 712927 2 FW .344X 1.00X.12 HRD Z
5 601364 601364 2 HINGE 3"X3" ZN W/ HOLES
6 601503 601503 8 CB .250-20 X .625 ZNYC
7 768515 768515 10 FW .281X.625X.051/.080H
8 601379 601379 1 SB .375 X 1.50SH .312-18
9 109745 109745 1 LIFT SUPPORT MOUNTING
10 063297 063297 1 SB .375X .500 SH .312-18
11 601564 601564 1 GAS SPRING HDZ HOOD
12 034272 034272 2 NT .312-18 HX G5 ZNYC
13 768523 768523 4 FW .343X.687X.051/.080H
14 601089 601089 4 RIVET .188 DIA BLK HD
15 010306 010306 2 LUDWIG SNAP FASTNER A-1
16 109136 109136 1 FIREWALL ACCESS PANEL
17 758821 758821 1 OVER CNTR CATCH W/LCK H
18 109413 109413 1 COVER REAR W/A HDZ
19 031666 031666 2 GM .31X.81X.56X.18
20 109105 109105 1 GUARD REAR ENGINE HDZ
21 767962 767962 4 FW .531X 1.063X.090 SAE
22 016527 016527 4 CS .500-13X1.00 HX G5 Z
23 055939 055939 4 CS .250-20X .750 HX G5
24 601373 601373 1 LATCH SLAM SOUTHCO
25 024927 024927 2 NT .250-20 HX GR.5 ZNYC
26 109721 109721 1 SOUTHCO LATCH BRACKET
27 029868 029868 2 LW .250 INT-EXT TOOTH Z
28 036236 036236 2 CS .312-18X1.000 HX G5
29 781880 781880 2 FW 1.312X 2.250X .160 P
30 109722 109722 1 LATCH STRIKER W/A
31 058776 058776 2 NT .312-18 HXZY NL
32 033035 033035 2 WEATHERSTRIP .12 X.75 X 6.25"
33 033035 033035 1 WEATHERSTRIP .12 X.75 X 11.88"
34 033035 033035 1 WEATHERSTRIP .12 X.75 X 19.88"
35 713198 713198 2 SEAL 3/8 X 3/4 X 4.5"
