Instrument panel – Hustler Turf Diesel Z User Manual
Page 51
109706 10/08
5-23
Instrument Panel
NOTES:
1. Part of wire harness (601367).
2. For wire harness connections see “Instrument panel and wire
connections (FIG. 1).” on page 10-3.
3. Service part includes decals. See “Tractor Decals” on page 9-2.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY.
DESCRIPTION
1
109557
109557
1
INSTRUMENT PANEL HDZ
2
109729
109729
1
FUEL TANK COVER HDZ
3
601089
601089
2
RIVET .188 DIA BLK HD
4
769166
769166
1
HOUR METER
5
385710011
N/A
1
TEMPERATURE GAUGE HDZ
6
601370
601370
1
FUEL GAUGE DUAL TANK HDZ
7
712257
712257
4
RED INDICATOR LIGHT
8
776476
776476
1
PTO SWITCH 6201-321
9
055947
055947
5
CS .250-20X .500 HX G5
10
768515
768515
5
FW .281X.625X.051/.080H
11
785808
785808
1
KEY ASSEMBLY
12
045898
045898
1
IGN SWITCH INDAK
13
601098
601098
1
CB 10-24 X .500 ZYNC
14
601053
N/A
1
SEALED RELAY W/BRACKET
15
059832
059832
1
NT #10-24 HX NL ZN
16
794347
794347
1
ULTRA LOUD WARBLE ALARM
17
063198
063198
2
CS 10-24X .750 HXFLK ZN
18
601368
601368
1
CONTROLLER HDZ S773L
19
601371
601371
1
GRIP RED 3/16X1 BAR HDZ
20
109420
109420
1
THROTTLE LEVER HDZ
21
036236
036236
8
CS .312-18X1.000 HX G5
22
768523
768523
10
FW .343X.687X.051/.080H
23
601069
601069
6
CN .312-18X.200 MAX THK
24
549378
109530
1
SEAT PAN COVER RH SIDE
25
549386
109531
1
SEAT PAN COVER LH SIDE
26
052860
052860
1
CS .375-16X1.250 HX G5
27
767954
767954
2
FW .406X .812 X.060 SAE
28
601507
601507
1
FW .406X1.000X.06 NYLON
29
712919
712919
1
FW .406X 1.00X.12 HRD Z
30
109421
109421
1
THROTTLE LEVER PLATE
31
016816
016816
2
NT .250-20 HX FL LK ZNY
32
056077
056077
1
CS .250-20X1.000 HX G5
33
601493
601493
1
SB .250DX.250L 10-24 ZN
34
601362
601362
1
THROTTLE CABLE HDZ
35
054502
054502
2
NT .375-16 HX GRD 5 ZNY
36
034272
034272
2
NT .312-18 HX G5 ZNYC
37
016774
016774
1
NT #10-24 HXFLK ZN
