Cooling System Installation
NOTES:
1. Coolant capacity: 6.0 US quarts.
2. Service part includes decals. See “Tractor Decals” on page 9-2.
3. For tractors with serial numbers prior to 08070401, use 706531
(Grommet).
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 036236 036236 6 CS .312-18X1.000 HX G5
2 768523 768523 21 FW .343X.687X.051/.080H
3 109559 109559 1 INNER PANEL FENDER
4 601069 601069 4 CN .312-18X.200 MAX THK
5 794644 794644 1 GM 1.50 X 2.12 X 1.75
706531 706531 1 GM 1.12X1.75X1.37X.12
6 016253 016253 7 CB .312-18X .750 FUL ZN
7 549360 109271 1 RAD SCREEN PANEL W/A HDZ
8 109137 109137 1 RADIATOR SCREEN W/A HDZ
9 601295 601295 1 RADIATOR HDZ
10 109144 109144 1 SHROUD W/A HDZ
11 068346 068346 4 CS .312-18X .500 HX G5
12 108977 108977 2 RAD MNT PLATE HDZ
13 034272 034272 11 NT .312-18 HX G5 ZNYC
14 713040 713040 4 HOSE CLAMP
15 601353 601353 1 UPPER RADIATOR HOSE
16 601354 601354 1 LOWER RADIATOR HOSE
17 549402 109073 1 HOOD SUPPORT
18 601358 601358 1 RADIATOR OVERFLOW BOTTLE
19 041483 041483 1 HOSE CLAMP
20 033035 033035 2 WEATHERSTRIP .12 X .75 X 1.5"
21 033035 033035 5 WEATHERSTRIP .12 X .75 X 16"
22 033035 033035 2 WEATHERSTRIP .12 X .75 X 15.5"
23 713198 713198 1 SEAL 3/8 X 3/4 X 14"
24 713198 713198 2 SEAL 3/8 X 3/4 X 1.25"
25 601558 601558 1 RADIATOR SUPPORT PAD
26 600320 N/A 1 RADIATOR CAP
