72" rear discharge deck assembly – Hustler Turf Diesel Z User Manual
Page 83
109706 10/08
7-23
72" Rear Discharge Deck Assembly
NOTES:
1. Factory assembled in top hole for shipping purposes.
2. Includes Items 15 through 17 and 19.
3. Service part deck includes decals, see ‘‘72" Rear Discharge Deck
4. When installing Items 22 and 24, Item 24 should be on top of Item 22.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY.
DESCRIPTION
1
549667
110450
1
72" REAR DISCHARGE DECK
2
109484
109484
1
DISCHARGE SHIELD
3
109485
109485
1
GUARD MOUNTING ANGLE
4
768523
768523
10
FW .343 X .687 X .051/.080 HD ZN
5
086660
086660
12
NT .375-16 HX LK NY
6
767954
767954
28
FW .406 X .812 X .060 SAE HD ZN
7
110471
110471
1
EXTENSION BRACKET RH 72"
8
110472
110472
1
EXTENSION BRACKET LH 72"
9
710194
710194
6
CB .375-16 X 1.50 STD G5
10
808485
808485
2
5/16-18 THREAD RIVET NUT
11
015495
015495
2
STRAIGHT GREASE FITTING
12
349803
349803
1
PUSHER
13
036244
036244
16
CS .375-16 X 1.00 HX G5 ZN
14
101477
101477
1
72" REAR DISCHARGE FRONT ANGLE
15
781708
N/A
4
CS .500-13 X 4.25 HX G5 ZN
16
767962
N/A
8
FW .531 X 1.063 X.090 SAE HD ZN
17
053199
N/A
4
NT .500-13 HX JAM ZN
18
781567
781567
4
NT .50-13 HX ZY NL
19
031997
N/A
4
ANTI-SCALP WHEEL
20
109486
109486
1
CLAMP ANGLE LS
21
109487
109487
1
CLAMP ANGLE RS
22
601483
601483
2
RUBBER SIDE FLAP
23
107712
107712
2
ANGLE, DISCHARGE CHUTE
24
600930
600930
2
RD REAR FLAP
25
109482
109482
1
CHUTE BRACKET
26
109483
109483
1
CHUTE BRACKET
27
778399
778399
2
FW .781 X 1.375 X .250 ZN YC
28
016253
016253
4
CB .312-18 X .750 FUL ZN
29
037887
037887
6
CB .312-18 X 1.000 FUL Z
30
058776
058776
10
NT .312-18 HX ZY NL
31
601069
601069
2
CN .312-18X.200
32
025395
025395
6
CB .375-16X 1.00 STD CD
788166
788166
4
ANTI SCALP WHEEL ASSEMBLY
3
4
4
2
1
